关于视野限制脚本与显示图片冲突的问题

xjzsq · 发表于 2015-7-8 22:08:48

加入我们，或者，欢迎回来。

您需要登录才可以下载或查看，没有账号？注册会员

×

我在制作的游戏中使用了视野限制的脚本，但是在我执行显示图片功能时，发现视野限制遮住了图片，只露出了视野没有限制的部分，如何改一下脚本，使这种情况不再发生。
我是这样想的：在显示图片时就释放视野限制（dispose），可以吗？
但是，我还不知道在哪里加（本人已有基础的脚本知识，正在进行进一步学习...）

喵呜喵5 · 发表于 2015-7-8 22:17:52

1.别这么干
2.在视野限制中搜索 z 或者self.z ，调整其z坐标的数值

xjzsq · 发表于 2015-7-8 22:21:36

喵呜喵5 发表于 2015-7-8 22:17
1.别这么干
2.在视野限制中搜索 z 或者self.z ，调整其z坐标的数值

那应该修改成多少呢？
我这上面是Z=199

tseyik · 发表于 2015-7-8 22:35:22

Galv's Visibility Range

#------------------------------------------------------------------------------#
# Galv's Visibility Range
#------------------------------------------------------------------------------#
# For: RPGMAKER VX ACE
# Version 1.1
#------------------------------------------------------------------------------#
# 2014-02-11 - Version 1.1 - added z level setting
# 2013-05-31 - Version 1.0 - release
#------------------------------------------------------------------------------#
# This script can make the player only able to see in a certain radius around
# themself. The rest is darkness. This size and opacity of this darkness is
# controlled using variables and turned on/off using a switch.
#
# Put this script below Materials and above main.
# Requires an image that can be found in the demo on galvs-scripts.com. Images
# for this script go in your /Graphics/System folder.
#------------------------------------------------------------------------------#
#------------------------------------------------------------------------------#
# SCRIPT CALL
#------------------------------------------------------------------------------#
# visimage("ImageName") # Can change the image used
#------------------------------------------------------------------------------#
($imported ||= {})["Galv_Vis_Range"] = true
module Galv_Vis
#------------------------------------------------------------------------------#
# SETTINGS - Don't forget to set these to unused variables and switch!
#------------------------------------------------------------------------------#
SWITCH = 5000 # This switch turns the visibility range on/off. Default OFF
SIZEVAR = 5000 # This variable controls how far player can see. Default 100
OPACITYVAR = 2 # This variable controls the darkness opacity. Default 255
Z_LEVEL = 0 # Make this higher or lower to change the z level
# (to make it appear above or below other stuff)
#------------------------------------------------------------------------------#
# END SETTINGS
#------------------------------------------------------------------------------#
end # Galv_Vis
class Spriteset_Map
alias galv_vis_sm_initialize initialize
def initialize
create_visrange if $game_switches[Galv_Vis::SWITCH]
galv_vis_sm_initialize
end
def create_visrange
@visrange = Sprite.new
@visrange.bitmap = Cache.system($game_system.visimage)
@visrange.ox = @visrange.bitmap.width / 2
@visrange.oy = @visrange.bitmap.height / 2
@visrange.z = Galv_Vis::Z_LEVEL
end
alias galv_vis_sm_update update
def update
galv_vis_sm_update
update_visrange
end
def update_visrange
if $game_switches[Galv_Vis::SWITCH]
create_visrange if !@visrange
@visrange.x = $game_player.screen_x
@visrange.y = $game_player.screen_y - 16
@visrange.opacity = $game_variables[Galv_Vis::OPACITYVAR]
zoom = [$game_variables[Galv_Vis::SIZEVAR].to_f * 0.01,0.5].max
@visrange.zoom_x = zoom
@visrange.zoom_y = zoom
else
dispose_visrange
end
end
alias galv_vis_sm_dispose dispose
def dispose
galv_vis_sm_dispose
dispose_visrange
end
def dispose_visrange
return if !@visrange
@visrange.bitmap.dispose
@visrange.dispose
@visrange = nil
end
end # Spriteset_Map
module DataManager
class << self
alias galv_vis_dm_setup_new_game setup_new_game
end
def self.setup_new_game
galv_vis_dm_setup_new_game
$game_system.init_visvars
end
end # DataManager
class Scene_Map
attr_accessor :spriteset
end
class Game_System
attr_accessor :visimage
def init_visvars
@visimage = "VisRange"
$game_variables[Galv_Vis::OPACITYVAR] = 255
$game_variables[Galv_Vis::SIZEVAR] = 100
end
end
class Game_Interpreter
def visimage(img)
$game_system.visimage = img
SceneManager.scene.spriteset.dispose_visrange
end
end

复制代码

放在Graphics\System


指定视野限制開関(予設5000)
紅黒切換
脚本
visimage("VisRangeRed")
visimage("VisRange")
指定视野限制大小変数(予設5000)
Z値(脚本内

xjzsq · 发表于 2015-7-9 17:23:15

tseyik 发表于 2015-7-8 22:35

Galv's Visibility Range

放在Graphics\System

我不是在求烛光系统的脚本，
是解决问题，请先搞清楚ME的意图...

[已经解决] 关于视野限制脚本与显示图片冲突的问题
