# ■ LCF_Leyeshot (linetype eyeshot)XP 2.2 Creator LCF Date 2009.7.6
#------------------------------------------------------------------------------
# 线形视野系统 编者:流川枫 QQ:350773875
#==============================================================================
#【使用说明】
#------------------------------------------------------------------------------
# 视野系统开关 $game_map.events[@event_id].le_seeing = true/false
# 功能:该值为true表示该NPC视野开启,否则未开启,默认为false。
#------------------------------------------------------------------------------
# 视野透视开关 $game_map.events[@event_id].le_clairv = true/false
# 功能:该值为true表示该NPC视野不扫描视线障碍,否则扫描,默认为false。
#------------------------------------------------------------------------------
# 视线显示开关 $game_map.events[@event_id].le_show = true/false
# 功能:该值为true表示显示该NPC的视线,否则不显示,默认为false。
#------------------------------------------------------------------------------
# 看见时显示开关 $game_map.events[@event_id].le_ss = true/false
# 功能:该值为true表示只有当NPC看见主角时才显示视线,否则一直显示,默认为false。
#------------------------------------------------------------------------------
# 侧面可视开关 $game_map.events[@event_id].le_side = true/false
# 功能:该值为true表示该NPC可以看到侧面一格内的人,否则由斜率决定,默认为true。
#------------------------------------------------------------------------------
# 视野环绕开关 $game_map.events[@event_id].le_circle = true/false
# 功能:该值为true表示该NPC为环绕视野,否则不能看见自己的身后,默认为false。
#------------------------------------------------------------------------------
# 设置视野深度 $game_map.events[@event_id].le_deepness = 深度值
# 功能:该值代表视野的能见度,当视野模型为扇形时应避免设置成奇数,默认为8。
#------------------------------------------------------------------------------
# 设置视野斜率 $game_map.events[@event_id].le_slope = 斜率值
# 功能:该值代表视野的斜率,默认为1.0。
#------------------------------------------------------------------------------
# 设置显示颜色 $game_map.events[@event_id].le_color = 颜色值
# 功能:该值代表视线显示的颜色,默认为0xf0。
#------------------------------------------------------------------------------
# 设置触发开关 $game_map.events[@event_id].le_skey = "A"/"B"/"C"/"D"(大写)
# 功能:该值指定了映射是否看见主角的状态的独立开关,默认为"D"。
#------------------------------------------------------------------------------
# 设置键开关 $game_map.events[@event_id].le_kw = true/false
# 功能:该值表示是否将该NPC触发状态映射到触发开关指定的独立变量中,默认为true。
#------------------------------------------------------------------------------
# 设置触发确认 $game_map.events[@event_id].le_true = true/false
# 功能:该值表示该NPC是否看见了主角,等价于触发开关,默认为false。
#------------------------------------------------------------------------------
# 设置视野模型 $game_map.events[@event_id].le_mode = 0/1
# 功能:该值为0时表示该NPC的视野形状类扇形,为1时类三角形,默认为0。
#==============================================================================
# 全局视野开关 $le_run = true/false
# 功能:该值为true表示系统正常工作,否则终止所有NPC的视野,默认为true。
#------------------------------------------------------------------------------
# 全局关闭列表 $le_close_table = ["A","B","C","D"]
# 功能:不同场景转移时,将自动关闭表里的独立开关。(只针对le_seeing为true的NPC)
#==============================================================================
# 当NPC看见主角,独立开关(le_skey)便会被打开,否则为关闭状态。
#==============================================================================
#==============================================================================
# ■ Game_Event
#------------------------------------------------------------------------------
# 重载事件类
#==============================================================================
class Game_Event
attr_accessor :le_seeing # 视野系统开关
attr_accessor :le_clairv # 视野透视开关
attr_accessor :le_show # 视线显示开关
attr_accessor :le_ss # 看见时显示开关
attr_accessor :le_side # 侧面可视开关
attr_accessor :le_circle # 视野环绕开关
attr_accessor :le_deepness # 视野深度
attr_accessor :le_slope # 视野斜率
attr_accessor :le_color # 显示颜色
attr_accessor :le_trace # 视野痕迹
attr_accessor :le_skey # 触发开关
attr_accessor :le_kw # 键开关
attr_accessor :le_true # 触发确认
attr_accessor :le_mode # 视野模型
#--------------------------------------------------------------------------
LE_DEEPNESS_OFFSET = 1 # 深度缓存的偏移
#--------------------------------------------------------------------------
# ● 初始化对像
# map_id : 地图 ID
# event : 事件 (RPG::Event)
#--------------------------------------------------------------------------
alias original_le_initialize initialize
def initialize (map_id, event)
original_le_initialize (map_id, event)
@le_seeing = false
@le_clairv = false
@le_show = false
@le_ss = false
@le_side = true
@le_circle = false
@le_deepness = 8
@le_slope = 1.0
@le_color = 0xf0
@le_trace = Table.new (@le_deepness-LE_DEEPNESS_OFFSET,2)
@le_trace[0,0] = -1
@le_kw = true
@le_true = false
@le_mode = 0
@le_skey = "D"
end
#--------------------------------------------------------------------------
# ● 刷新
#--------------------------------------------------------------------------
alias original_le_update update
def update
original_le_update
if @le_seeing and $le_run
@le_trace.resize (@le_deepness-LE_DEEPNESS_OFFSET,2) if @le_trace.xsize+LE_DEEPNESS_OFFSET != @le_deepness
self.see
if @le_kw
$game_map.need_refresh = true if @le_true != $game_self_switches[[$game_map.map_id, @id, @le_skey]]
$game_self_switches[[$game_map.map_id, @id, @le_skey]] = @le_true
end
end
end
#--------------------------------------------------------------------------
# ● 视野检测
#--------------------------------------------------------------------------
def see
@le_true = false
if ($game_player.x-@x).abs<@le_deepness and ($game_player.y-@y).abs<@le_deepness
difference_x = ($game_player.x - @x).abs
difference_y = ($game_player.y - @y).abs
case @direction
when 2
return if @le_circle != true and $game_player.y < @y
unless @le_side and (difference_y == 0 and difference_x == 1)
return if difference_x.to_f/difference_y > @le_slope
end
when 4
return if @le_circle != true and $game_player.x > @x
unless @le_side and difference_y == 1 and difference_x == 0
return if difference_y.to_f/difference_x > @le_slope
end
when 6
return if @le_circle != true and $game_player.x < @x
unless @le_side and difference_y == 1 and difference_x == 0
return if difference_y.to_f/difference_x > @le_slope
end
else
return if @le_circle != true and $game_player.y > @y
unless @le_side and difference_y == 0 and difference_x == 1
return if difference_x.to_f/difference_y > @le_slope
end
end
if @le_mode == 0
return if (difference_x ** 2 + difference_y ** 2) > le_deepness ** 2
end
@le_true = scan_line
if @le_ss and @le_true !=true
@le_trace[0,0] = -1
end
end
end
#--------------------------------------------------------------------------
# ● 视线检测 采用了国际领先的视线扫描算法!
#--------------------------------------------------------------------------
def scan_line
difference_x = $game_player.x - @x
difference_y = $game_player.y - @y
direction_x = (difference_x > 0 ? 1 : -1)
direction_y = (difference_y > 0 ? 1 : -1)
i = 0
if difference_x.abs > difference_y.abs
while difference_x.abs > i+1
i+=1
x = @x+i*direction_x
if direction_y>0
y = @y+i*difference_y/difference_x.to_f*direction_y*direction_x+0.5
else
y = @y-i*difference_y/difference_x.to_f*direction_y*direction_x+0.5
end
x = x.floor
y = y.floor
if @le_clairv != true
unless (direction_x > 0 ? passable?(x-1,y,6) : passable?(x+1,y,4))
@le_trace[i-1,0] = -1
return false
end
end
if @le_show
@le_trace[i-1,0] = x
@le_trace[i-1,1] = y
end
end
else
while difference_y.abs > i+1
i+=1
y = @y+i*direction_y
if direction_x>0
x = @x+i*difference_x/(difference_y+0.0)*direction_x*direction_y+0.5
else
x = @x-i*difference_x/(difference_y+0.0)*direction_x*direction_y+0.5
end
x = x.floor
y = y.floor
if @le_clairv != true
unless (direction_y > 0 ? passable?(x,y-1,2) : passable?(x,y+1,8))
@le_trace[i-1,0] = -1
return false
end
end
if @le_show
@le_trace[i-1,0] = x
@le_trace[i-1,1] = y
end
end
end
@le_trace[i,0] = -1
return true
end
end
#==============================================================================
# ■ Spriteset_Map
#------------------------------------------------------------------------------
# 重载地图显示
#==============================================================================
class Spriteset_Map
attr_reader:tilemap
alias :original_le_initialize :initialize
def initialize
original_le_initialize
@tilemap.flash_data=Table.new(@tilemap.map_data.xsize,@tilemap.map_data.ysize)
end
end
#==============================================================================
# ■ Scene_Map
#------------------------------------------------------------------------------
# 重载地图场景
#==============================================================================
class Scene_Map
attr_reader:spriteset
#--------------------------------------------------------------------------
# ● 主角的场所移动
#--------------------------------------------------------------------------
alias original_le_transfer_player transfer_player
def transfer_player
# 自动关闭当前地图上le_seeing为true的NPC独立开关
if $game_map.map_id != $game_temp.player_new_map_id
for event in $game_map.events.values
if event.le_seeing
for key in $le_close_table
$game_self_switches[[$game_map.map_id,event.id, key]] =false
end
end
end
end
original_le_transfer_player
end
#--------------------------------------------------------------------------
# ● 主处理
#--------------------------------------------------------------------------
def main
# 生成活动块
@spriteset = Spriteset_Map.new
# 生成信息窗口
@message_window = Window_Message.new
# 执行过渡
Graphics.transition
# 主循环
loop do
# 刷新游戏画面
Graphics.update
# 刷新输入信息
Input.update
#==========================
# 清除LE视野产生的痕迹
#==========================
for event in $game_map.events.values
for i in 0 .. event.le_trace.xsize-1
break if event.le_trace[i,0] == -1
$scene.spriteset.tilemap.flash_data[event.le_trace[i,0],event.le_trace[i,1]] = 0
end
event.le_trace[0,0] = -1
end
#==========================
# 刷新画面
update
# 如果画面切换的话就中断循环
if $scene != self
break
end
#==========================
# 刷新LE视野路径
#==========================
for event in $game_map.events.values
for i in 0 .. event.le_trace.xsize-1
break if event.le_trace[i,0] == -1
$scene.spriteset.tilemap.flash_data[event.le_trace[i,0],event.le_trace[i,1]] = event.le_color
end
end
#==========================
end
# 准备过渡
Graphics.freeze
# 释放活动块
@spriteset.dispose
# 释放信息窗口
@message_window.dispose
# 标题画面切换中的情况下
if $scene.is_a?(Scene_Title)
# 淡入淡出画面
Graphics.transition
Graphics.freeze
end
end
end
#==============================================================================
# ■ Scene_Title
#------------------------------------------------------------------------------
# 处理标题画面的类。
#==============================================================================
class Scene_Title
alias original_le_main main
def main
$le_run = true
$le_close_table = ["A","B","C","D"]
original_le_main
end
end
#==============================================================================
# ■ Scene_Save
#------------------------------------------------------------------------------
# 处理存档画面的类。
#==============================================================================
class Scene_Save < Scene_File
# 写入两个全局变量
alias original_le_write_save_data write_save_data
def write_save_data(file)
original_le_write_save_data(file)
Marshal.dump($le_run,file)
Marshal.dump($le_close_table,file)
end
end
#==============================================================================
# ■ Scene_Load
#------------------------------------------------------------------------------
# 处理读档画面的类。
#==============================================================================
class Scene_Load < Scene_File
# 读取两个全局变量
alias original_le_read_save_data read_save_data
def read_save_data(file)
original_le_read_save_data(file)
$le_run = Marshal.load(file)
$le_close_table = Marshal.load(file)
end
end
#==============================================================================
# The End
#==============================================================================
