楼主 |
发表于 2018-6-7 17:10:04
|
显示全部楼层
本帖最后由 tseyik 于 2018-6-10 22:46 编辑
Ultra Mode 7 v1.1.0
作者Blizzard
發佈頁
https://forums.rpgmakerweb.com/i ... ultra-mode-7.94100/
点击展开／收起[pre lang="javascript"]/*:
@plugindesc Renders the tilemap in 3D. Supports various parameters such as yaw rotation,
pitch, field of view, etc.
@author Blizzard
@help Version: 1.1.0
--Introduction--
Ultra Mode 7 simulates the Mode 7 rendering mode from the SNES by using 3D
rendering. Sprites are scaled appropriately and use additional code to
determine whether they are visible, because of cut-off distance. The view
of a Mode 7 map is defined by the following parameters:
- camera distance
- field of view
- pitch rotation angle
- yaw rotation angle
- maximum Z coordinate
--Changelog--
v1.1.0:
- added animation function for parameters
- renamed RENDER_PIXELATED option to TILEMAP_PIXELATED
- added CHARACTERS_PIXELATED option
- fixed issue with floating characters
- fixed issue with normal maps not working anymore
- added some code to prevent compatibility issues with some map scripts
--How to use--
Separate maps can control and even dynamically change most paramaters. In
order to turn a normal map into a Mode 7 map, custom parameters need to be
defined in the "Note" section of the map. To use the default values for a
map, simply add the following entry to the map "note":
<UltraMode7>
If any other parameter is defined, this is not necessary. The following
parameters can be defined:
- UltraMode7_FOV
- UltraMode7_Pitch
- UltraMode7_Yaw
- UltraMode7_CameraDistance
Example:
<UltraMode7_FOV:50>
When multiple parameters are defined, simply add them one after another.
Example:
<UltraMode7_Pitch:50>
<UltraMode7_CameraDistance:400>
<UltraMode7_Yaw:45>
--How to change parameters dynamically--
The 4 parameters that can be defined in the note section of a map can also
be changed at any time during the map. Following script calls are available:
UltraMode7.setFov(DEGREES)
UltraMode7.setPitch(DEGREES)
UltraMode7.setYaw(DEGREES)
UltraMode7.setCamera(Z_DISTANCE)
You can also obtain the current values with these script calls:
UltraMode7.getFov()
UltraMode7.getPitch()
UltraMode7.getYaw()
UltraMode7.getCamera()
You can also change the values in an animated manner:
UltraMode7.animateFov(TARGET_VALUE, FRAMES_DURATION)
UltraMode7.animatePitch(TARGET_VALUE, FRAMES_DURATION)
UltraMode7.animateYaw(TARGET_VALUE, FRAMES_DURATION)
UltraMode7.animateCamera(TARGET_VALUE, FRAMES_DURATION)
--Additional Notes--
- When using parallax backgrounds, due to how rendering is done, it's useful
to have a custom parallax that fades into white and creates a seamless
transition into the faded tiles.
- Smaller values of FAR_CLIP_Z will cause characters and the tilemap
to be cut off earlier. Effectively it moves the cut-off horizon closer.
- If you don't want white fade-out, set both FADE_Z values to a larger value
than FAR_CLIP_Z.
- When the yaw value is changed, characters are turned around accordingly.
- Consider using the same values for BASE_SCALE_Z and DEFAULT_CAMERA_DISTANCE.
--Technical details, limitations and compatibility--
- Requires WebGL. Does not work with canvas and due to how canvas works, it
can never support canvas.
- Due to sprite scaling, how character sprite sheets are organized and how
pixel interpolation is done when scaling is applied, there can be artifacts
during rendering of characters. Manipulating the FAR_CLIP_Z value can
help remove these artifacts to some degree.
- The tilemap is rendered in its entirety and the projection matrix is used
to limit visibility. The hardware should take care of optimizing rendering.
- Character sprite visibility is done by moving the character sprite to the
coordinates (-10000,-10000) in order to avoid messing with sprite
visibility and hence compatibility.
- Due to a hard limit of 65536 vertices being rendered at once in WebGL, the
code has been adjusted to render the tilemap in as many passes as necessary.
Since some people reported issues even with 65536 vertices, a soft limit of
65532 is being used.
- Because the tilemap is rendered entirely flat, tile priority isn't used.
- Scaling has been optimized for usage of an FOV of 60°. Using different
values will cause some weird scales being used for characters.
- Due to yaw rotation requiring turning of characters, 8-directional
characters sprites might have only limited support.
- Possibly not compatible with scripts that manipulate tilemap data too much
or too deeply.
- Looping maps are currently not supported.
@param FAR_CLIP_Z
@desc Defines The maximum Z-coordinate for visibility of tiles and characters.
@default 1200
@param FADE_Z_BEGIN
@desc Defines The Z-coordinate at which white fading will start on the tilemap.
@default 500
@param FADE_Z_END
@desc Defines The Z-coordinate at which white fading will be at full on the tilemap.
@default 1150
@param BASE_SCALE_Z
@desc Defines The Z-coordinate at which character scaling is 1.0.
@default 450
@param PARALLAX_SCROLL_X_MULTIPLIER
@desc Defines The multiplier for parallax X-scrolling.
@default 0.5
@param PARALLAX_SCROLL_Y_MULTIPLIER
@desc Defines The multiplier for parallax Y-scrolling.
@default 1.0
@param TILEMAP_PIXELATED
@desc Whether the tilemap should be rendered pixelated.
ON = true, OFF = false
@default true
@param CHARACTERS_PIXELATED
@desc Whether the characters should be rendered pixelated.
ON = true, OFF = false
@default true
@param DEFAULT_FOV
@desc Defines The default value for the field-of-view parameter (in degrees).
@default 60
@param DEFAULT_PITCH
@desc Defines The default value for the pitch rotation angle parameter (in degrees).
@default 45
@param DEFAULT_YAW
@desc Defines The default value for the yaw rotation angle parameter (in degrees).
@default 0
@param DEFAULT_CAMERA_DISTANCE
@desc Defines The default distance of the camera from the tilemap in screen space.
@default 450
*/
//=============================================================================
// Ultra Mode 7
//=============================================================================
(function() {
if (!Graphics.hasWebGL())
{
console.error("Ultra Mode 7 requires WebGL support!");
return;
}
//=============================================================================
// BlizzardUtility
//=============================================================================
if (typeof(BlizzardUtility) === "undefined")
{
BlizzardUtility = function()
{
throw new Error("This is a static class");
};
BlizzardUtility.degreesToRadians = function(degrees)
{
return (degrees * 0.01745329251994329576923690768489);
};
BlizzardUtility.radiansToDegrees = function(radians)
{
return (radians * 57.295779513082320876798154814105);
};
BlizzardUtility.Numeric = function(value, defaultValue)
{
var result = Number(value);
if (result || result === 0)
{
return result;
}
return defaultValue;
}
}
//=============================================================================
// UltraMode7
//=============================================================================
UltraMode7 = {};
// constants
// NOTE: Don't change these unless you know what you are doing!
UltraMode7.WEBGL_MAX_VERTICES = 65532; // stay under the WebGL limit of 65536, some have reported bugs
UltraMode7.NEAR_CLIP_Z = 10;
UltraMode7.MIN_FOV = 10;
UltraMode7.MIN_PITCH = 0;
UltraMode7.MAX_PITCH = 90;
// configuration parameters
var _parameters = PluginManager.parameters("UltraMode7");
UltraMode7.FAR_CLIP_Z = Math.max(BlizzardUtility.Numeric(_parameters["FAR_CLIP_Z"], 1200), UltraMode7.NEAR_CLIP_Z + 1);
UltraMode7.FADE_Z_BEGIN = BlizzardUtility.Numeric(_parameters["FADE_Z_BEGIN"], 500);
UltraMode7.FADE_Z_END = BlizzardUtility.Numeric(_parameters["FADE_Z_END"], 1150);
UltraMode7.BASE_SCALE_Z = BlizzardUtility.Numeric(_parameters["BASE_SCALE_Z"], 450);
UltraMode7.PARALLAX_SCROLL_X_MULTIPLIER = BlizzardUtility.Numeric(_parameters["PARALLAX_SCROLL_X_MULTIPLIER"], 0.5);
UltraMode7.PARALLAX_SCROLL_Y_MULTIPLIER = BlizzardUtility.Numeric(_parameters["PARALLAX_SCROLL_Y_MULTIPLIER"], 1.0);
UltraMode7.TILEMAP_PIXELATED = JSON.parse(_parameters["TILEMAP_PIXELATED"]);
UltraMode7.CHARACTERS_PIXELATED = JSON.parse(_parameters["CHARACTERS_PIXELATED"]);
UltraMode7.DEFAULT_FOV = BlizzardUtility.Numeric(_parameters["DEFAULT_FOV"], 60);
UltraMode7.DEFAULT_PITCH = BlizzardUtility.Numeric(_parameters["DEFAULT_PITCH"], 45);
UltraMode7.DEFAULT_YAW = BlizzardUtility.Numeric(_parameters["DEFAULT_YAW"], 0);
UltraMode7.DEFAULT_CAMERA_DISTANCE = BlizzardUtility.Numeric(_parameters["DEFAULT_CAMERA_DISTANCE"], 450);
// interface functions for script calls
UltraMode7.getFov = function()
{
return $gameMap.ultraMode7Fov;
};
UltraMode7.setFov = function(value)
{
$gameMap.setUltraMode7Fov(value);
};
UltraMode7.getPitch = function()
{
return $gameMap.ultraMode7Pitch;
};
UltraMode7.setPitch = function(value)
{
$gameMap.setUltraMode7Pitch(value);
};
UltraMode7.getYaw = function()
{
return $gameMap.ultraMode7Yaw;
};
UltraMode7.setYaw = function(value)
{
$gameMap.setUltraMode7Yaw(value);
};
UltraMode7.getCamera = function()
{
return $gameMap.ultraMode7CameraDistance;
};
UltraMode7.setCamera = function(value)
{
$gameMap.setUltraMode7CameraDistance(value);
};
UltraMode7.animateFov = function(target, frameDuration)
{
$gameMap.animateUltraMode7Fov(target, frameDuration);
};
UltraMode7.animatePitch = function(target, frameDuration)
{
$gameMap.animateUltraMode7Pitch(target, frameDuration);
};
UltraMode7.animateYaw = function(target, frameDuration)
{
$gameMap.animateUltraMode7Yaw(target, frameDuration);
};
UltraMode7.animateCamera = function(target, frameDuration)
{
$gameMap.animateUltraMode7CameraDistance(target, frameDuration);
};
// functions
UltraMode7.screenToMap = function(x, y)
{
// transform 2 point ray from projection into world
var projectionMatrix = $gameMap.ultraMode7ProjectionMatrix;
var halfWidth = Graphics.boxWidth / 2;
var halfHeight = Graphics.boxHeight / 2;
var origin = new UltraMode7.Vector3(x - halfWidth, y - halfHeight, -1);
var target = new UltraMode7.Vector3(x - halfWidth, y - halfHeight, 1);
if ($gameMap.ultraMode7Fov > 0)
{
var scaleZ = projectionMatrix.data[10];
var offsetZ = projectionMatrix.data[14];
origin.x = origin.x * (offsetZ - origin.z) / scaleZ / halfWidth;
origin.y = origin.y * (offsetZ - origin.z) / scaleZ / halfHeight;
target.x = target.x * (offsetZ - target.z) / scaleZ / halfWidth;
target.y = target.y * (offsetZ - target.z) / scaleZ / halfHeight;
}
else
{
target = origin.plused(target);
}
projectionMatrix = projectionMatrix.inversed();
origin = projectionMatrix.multiplied(origin);
target = projectionMatrix.multiplied(target);
var mapWidth = $gameMap.width() * $gameMap.tileWidth();
var mapHeight = $gameMap.height() * $gameMap.tileHeight();
// first transform 4 points from model into world space
var modelviewMatrix = $gameMap.ultraMode7ModelviewMatrix;
var topLeft = modelviewMatrix.multiplied(new UltraMode7.Vector3(0, 0, 0));
var topRight = modelviewMatrix.multiplied(new UltraMode7.Vector3(mapWidth, 0, 0));
var bottomLeft = modelviewMatrix.multiplied(new UltraMode7.Vector3(0, mapHeight, 0));
var bottomRight = modelviewMatrix.multiplied(new UltraMode7.Vector3(mapWidth, mapHeight, 0));
// solve equation Ax + By + Cz + D = 0
var equations = [
[topLeft.x, topLeft.y, topLeft.z, 0],
[topRight.x, topRight.y, topRight.z, 0],
[bottomLeft.x, bottomLeft.y, bottomLeft.z, 0],
[bottomRight.x, bottomRight.y, bottomRight.z, 0]
];
var factors = UltraMode7._solveLinearEquationWithGuassianElimination(equations);
// create plane equation
var ray = target.minused(origin);
var normal = new UltraMode7.Vector3(factors[0], factors[1], factors[2]);
ray.multiply((factors[3] - normal.dotted(origin)) / normal.dotted(ray));
var intersection = origin.plused(ray);
return modelviewMatrix.inversed().multiplied(intersection);
};
UltraMode7._solveLinearEquationWithGuassianElimination = function(M)
{
var i;
var j;
var k;
var n = M.length;
for (i = 0; i < n; ++i)
{
M.push(1);
}
for (i = 0; i < n; ++i)
{
// Search for maximum in this column
var maxEl = Math.abs(M);
var maxRow = i;
for (k = i + 1; k < n; ++k)
{
if (Math.abs(M[k]) > maxEl)
{
maxEl = Math.abs(M[k]);
maxRow = k;
}
}
// Swap maximum row with current row (column by column)
for (k = i; k < n + 1; ++k)
{
var tmp = M[maxRow][k];
M[maxRow][k] = M[k];
M[k] = tmp;
}
if (M !== 0)
{
// Make all rows below this one 0 in current column
for (k = i + 1; k < n; ++k)
{
var c = -M[k] / M;
for (j = i; j < n + 1; ++j)
{
if (i === j)
{
M[k][j] = 0;
}
else
{
M[k][j] += c * M[j];
}
}
}
}
}
// Solve equation Mx=b for the upper triangular matrix M
result = [];
for (i = n - 1; i >= 0; --i)
{
if (M === 0)
{
result = 1;
}
else
{
result = M[n] / M;
}
for (k = i - 1; k >= 0; --k)
{
M[k][n] -= M[k] * result;
}
}
return result;
};
UltraMode7.mapToScreen = function(x, y)
{
var position = new UltraMode7.Vector3(x + $gameMap.displayX() * $gameMap.tileWidth(), y + $gameMap.displayY() * $gameMap.tileHeight(), 0);
var worldPosition = $gameMap.ultraMode7ModelviewMatrix.multiplied(position);
var projection = $gameMap.ultraMode7ProjectionMatrix;
var result = projection.multiplied(worldPosition);
// W is needed for perspective projection
var vectorW = projection.data[3] * worldPosition.x + projection.data[7] * worldPosition.y + projection.data[11] * worldPosition.z + projection.data[15];
// calculate perspective projection and offset to screen coordinates
result.x = result.x * Graphics.boxWidth / 2 / vectorW + Graphics.boxWidth / 2;
result.y = result.y * Graphics.boxHeight / 2 / vectorW + Graphics.boxHeight / 2;
return result;
};
UltraMode7.mapToScreenScale = function(x, y)
{
return UltraMode7.mapZToScreenScale(UltraMode7.mapToScreen(x, y).z);
};
UltraMode7.mapZToScreenScale = function(z)
{
return (UltraMode7.BASE_SCALE_Z / Math.abs(z));
};
//=============================================================================
// Vector3
//=============================================================================
UltraMode7.Vector3 = function(x, y, z)
{
this.x = (x || 0);
this.y = (y || 0);
this.z = (z || 0);
};
UltraMode7.Vector3.prototype.set = function(x, y, z)
{
this.x = x;
this.y = y;
this.z = z;
};
UltraMode7.Vector3.prototype.length = function()
{
return Math.sqrt(this.x * this.x + this.y * this.y + this.z * this.z);
};
UltraMode7.Vector3.prototype.normalize = function()
{
var length = this.length();
if (length !== 0)
{
length = 1 / length;
this.x *= length;
this.y *= length;
this.z *= length;
}
};
UltraMode7.Vector3.prototype.negative = function()
{
this.x = -this.x;
this.y = -this.y;
this.z = -this.z;
};
UltraMode7.Vector3.prototype.multiply = function(factor)
{
this.x *= factor;
this.y *= factor;
this.z *= factor;
};
UltraMode7.Vector3.prototype.plused = function(other)
{
return new UltraMode7.Vector3(this.x + other.x, this.y + other.y, this.z + other.z);
};
UltraMode7.Vector3.prototype.minused = function(other)
{
return new UltraMode7.Vector3(this.x - other.x, this.y - other.y, this.z - other.z);
};
UltraMode7.Vector3.prototype.averaged = function(other)
{
return new UltraMode7.Vector3((this.x + other.x) / 2, (this.y + other.y) / 2, (this.z + other.z) / 2);
};
UltraMode7.Vector3.prototype.dotted = function(other)
{
return (this.x * other.x + this.y * other.y + this.z * other.z);
}
UltraMode7.Vector3.prototype.crossed = function(other)
{
return new UltraMode7.Vector3(this.y * other.z - this.z * other.y, this.z * other.x - this.x * other.z, this.x * other.y - this.y * other.x);
};
//=============================================================================
// Matrix4
//=============================================================================
UltraMode7.Matrix4 = function(data)
{
if (data)
{
this.data = data.slice();
}
else
{
this.data = [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1];
}
};
UltraMode7.Matrix4.prototype.setIdentity = function()
{
this.setZero();
this.data[0] = this.data[5] = this.data[10] = this.data[15] = 1;
};
UltraMode7.Matrix4.prototype.setZero = function()
{
for (var i = 0; i < 16; ++i)
{
this.data = 0;
}
};
UltraMode7.Matrix4.prototype.set = function(data)
{
this.data = data.slice();
};
UltraMode7.Matrix4.prototype.setTranslation = function(vector)
{
this.setIdentity();
this.data[12] = vector.x;
this.data[13] = vector.y;
this.data[14] = vector.z;
};
UltraMode7.Matrix4.prototype.translate = function(x, y, z)
{
var matrix = new UltraMode7.Matrix4();
matrix.setTranslation(new UltraMode7.Vector3(x, y, z));
this.multiply(matrix);
};
UltraMode7.Matrix4.prototype.rotateX = function(angle)
{
var matrix = new UltraMode7.Matrix4();
matrix.setRotationX(angle);
this.multiply(matrix);
};
UltraMode7.Matrix4.prototype.rotateY = function(angle)
{
var matrix = new UltraMode7.Matrix4();
matrix.setRotationY(angle);
this.multiply(matrix);
};
UltraMode7.Matrix4.prototype.rotateZ = function(angle)
{
var matrix = new UltraMode7.Matrix4();
matrix.setRotationZ(angle);
this.multiply(matrix);
};
UltraMode7.Matrix4.prototype.setRotationX = function(angle)
{
this.setZero();
var rad = BlizzardUtility.degreesToRadians(angle);
this.data[0] = this.data[15] = 1;
this.data[5] = this.data[10] = Math.cos(rad);
this.data[6] = Math.sin(rad);
this.data[9] = -this.data[6];
};
UltraMode7.Matrix4.prototype.setRotationY = function(angle)
{
this.setZero();
var rad = BlizzardUtility.degreesToRadians(angle);
this.data[5] = this.data[15] = 1;
this.data[0] = this.data[10] = Math.cos(rad);
this.data[8] = Math.sin(rad);
this.data[2] = -this.data[8];
};
UltraMode7.Matrix4.prototype.setRotationZ = function(angle)
{
this.setZero();
var rad = BlizzardUtility.degreesToRadians(angle);
this.data[10] = this.data[15] = 1;
this.data[0] = this.data[5] = Math.cos(rad);
this.data[1] = Math.sin(rad);
this.data[4] = -this.data[1];
};
UltraMode7.Matrix4.prototype.multiply = function(other)
{
this.set([this.data[0] * other.data[0] + this.data[4] * other.data[1] + this.data[8] * other.data[2] + this.data[12] * other.data[3],
this.data[1] * other.data[0] + this.data[5] * other.data[1] + this.data[9] * other.data[2] + this.data[13] * other.data[3],
this.data[2] * other.data[0] + this.data[6] * other.data[1] + this.data[10] * other.data[2] + this.data[14] * other.data[3],
this.data[3] * other.data[0] + this.data[7] * other.data[1] + this.data[11] * other.data[2] + this.data[15] * other.data[3],
this.data[0] * other.data[4] + this.data[4] * other.data[5] + this.data[8] * other.data[6] + this.data[12] * other.data[7],
this.data[1] * other.data[4] + this.data[5] * other.data[5] + this.data[9] * other.data[6] + this.data[13] * other.data[7],
this.data[2] * other.data[4] + this.data[6] * other.data[5] + this.data[10] * other.data[6] + this.data[14] * other.data[7],
this.data[3] * other.data[4] + this.data[7] * other.data[5] + this.data[11] * other.data[6] + this.data[15] * other.data[7],
this.data[0] * other.data[8] + this.data[4] * other.data[9] + this.data[8] * other.data[10] + this.data[12] * other.data[11],
this.data[1] * other.data[8] + this.data[5] * other.data[9] + this.data[9] * other.data[10] + this.data[13] * other.data[11],
this.data[2] * other.data[8] + this.data[6] * other.data[9] + this.data[10] * other.data[10] + this.data[14] * other.data[11],
this.data[3] * other.data[8] + this.data[7] * other.data[9] + this.data[11] * other.data[10] + this.data[15] * other.data[11],
this.data[0] * other.data[12] + this.data[4] * other.data[13] + this.data[8] * other.data[14] + this.data[12] * other.data[15],
this.data[1] * other.data[12] + this.data[5] * other.data[13] + this.data[9] * other.data[14] + this.data[13] * other.data[15],
this.data[2] * other.data[12] + this.data[6] * other.data[13] + this.data[10] * other.data[14] + this.data[14] * other.data[15],
this.data[3] * other.data[12] + this.data[7] * other.data[13] + this.data[11] * other.data[14] + this.data[15] * other.data[15]]);
};
UltraMode7.Matrix4.prototype.multiplied = function(vector)
{
return new UltraMode7.Vector3(this.data[0] * vector.x + this.data[4] * vector.y + this.data[8] * vector.z + this.data[12],
this.data[1] * vector.x + this.data[5] * vector.y + this.data[9] * vector.z + this.data[13],
this.data[2] * vector.x + this.data[6] * vector.y + this.data[10] * vector.z + this.data[14]);
};
UltraMode7.Matrix4.prototype.lookAt = function(eye, target, up)
{
this.setZero();
var bz = eye.minused(target);
bz.normalize();
var bx = up.crossed(bz);
bx.normalize();
var by = bz.crossed(bx);
by.normalize();
this.data[0] = bx.x; this.data[1] = by.x; this.data[2] = bz.x;
this.data[4] = bx.y; this.data[5] = by.y; this.data[6] = bz.y;
this.data[8] = bx.z; this.data[9] = by.z; this.data[10] = bz.z; this.data[15] = 1;
eye.negative();
var b = new UltraMode7.Matrix4();
b.setTranslation(eye);
this.multiply(b);
};
UltraMode7.Matrix4.prototype.setPerspective = function(fov, width, height, nearZ, farZ)
{
this.setZero();
var iy = 1 / Math.tan(BlizzardUtility.degreesToRadians(fov * 0.5));
var zDiff = farZ - nearZ;
this.data[0] = iy * height / width;
this.data[5] = iy;
this.data[10] = -(farZ + nearZ) / zDiff;
this.data[11] = -1;
this.data[14] = -2 * farZ * nearZ / zDiff;
};
UltraMode7.Matrix4.prototype.setOrthoProjection = function(x, y, w, h)
{
this.setZero();
this.data[0] = 2 / w;
this.data[5] = 2 / h;
this.data[12] = x * 2 / w;
this.data[13] = -y * 2 / h;
this.data[15] = 1;
};
UltraMode7.Matrix4.prototype.inversed = function()
{
var invDet = 1 / this.determinant();
m = [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1];
m[0] = (this.data[5] * this.data[10] - this.data[9] * this.data[6]) * invDet;
m[1] = -(this.data[1] * this.data[10] - this.data[9] * this.data[2]) * invDet;
m[2] = (this.data[1] * this.data[6] - this.data[5] * this.data[2]) * invDet;
m[4] = -(this.data[4] * this.data[10] - this.data[8] * this.data[6]) * invDet;
m[5] = (this.data[0] * this.data[10] - this.data[8] * this.data[2]) * invDet;
m[6] = -(this.data[0] * this.data[6] - this.data[4] * this.data[2]) * invDet;
m[8] = (this.data[4] * this.data[9] - this.data[8] * this.data[5]) * invDet;
m[9] = -(this.data[0] * this.data[9] - this.data[8] * this.data[1]) * invDet;
m[10] = (this.data[0] * this.data[5] - this.data[4] * this.data[1]) * invDet;
m[12] = -(this.data[12] * m[0] + this.data[13] * m[4] + this.data[14] * m[8]);
m[13] = -(this.data[12] * m[1] + this.data[13] * m[5] + this.data[14] * m[9]);
m[14] = -(this.data[12] * m[2] + this.data[13] * m[6] + this.data[14] * m[10]);
return new UltraMode7.Matrix4(m);
};
UltraMode7.Matrix4.prototype.determinant = function()
{
return (this.data[0] * this.data[5] * this.data[10] +
this.data[4] * this.data[9] * this.data[2] +
this.data[8] * this.data[1] * this.data[6] -
this.data[8] * this.data[5] * this.data[2] -
this.data[4] * this.data[1] * this.data[10] -
this.data[0] * this.data[9] * this.data[6]);
};
UltraMode7.Matrix4.prototype.transpose = function()
{
this.set([this.data[0], this.data[4], this.data[8], this.data[12],
this.data[1], this.data[5], this.data[9], this.data[13],
this.data[2], this.data[6], this.data[10], this.data[14],
this.data[3], this.data[7], this.data[11], this.data[15]]);
};
//=============================================================================
// Shader
//=============================================================================
UltraMode7.Shader = (function(_super)
{
RECT_SHADER_VERTEX = "\n\
attribute vec2 aVertexPosition;\n\
attribute vec2 aTextureCoord;\n\
attribute vec4 aFrame;\n\
attribute vec2 aAnim;\n\
attribute float aTextureId;\n\
\n\
uniform mat4 mode7ProjectionMatrix;\n\
uniform mat4 mode7ModelviewMatrix;\n\
uniform vec2 animationFrame;\n\
\n\
varying vec2 vTextureCoord;\n\
varying vec4 vFrame;\n\
varying float vTextureId;\n\
varying float vFade;\n\
\n\
void main(void){\n\
vec4 position = mode7ModelviewMatrix * vec4(aVertexPosition, 0.0, 1.0);\n\
position = mode7ProjectionMatrix * vec4(position.x, position.y, position.z, position.w);\
gl_Position = position;\
vec2 anim = aAnim * animationFrame;\n\
vTextureCoord = aTextureCoord + anim;\n\
vFrame = aFrame + vec4(anim, anim);\n\
vTextureId = aTextureId;\n\
vFade = clamp((position.z - " + UltraMode7.FADE_Z_BEGIN.toFixed(2) + ") / " + (UltraMode7.FADE_Z_END - UltraMode7.FADE_Z_BEGIN).toFixed(2) + ", 0.0, 1.0);\n\
}\n";
RECT_SHADER_FRAGMENT = "\
varying vec2 vTextureCoord;\n\
varying vec4 vFrame;\n\
varying float vTextureId;\n\
varying float vFade;\n\
uniform vec4 shadowColor;\n\
uniform sampler2D uSamplers[%count%];\n\
uniform vec2 uSamplerSize[%count%];\n\
\n\
void main(void){\n\
vec2 textureCoord = clamp(vTextureCoord, vFrame.xy, vFrame.zw);\n\
float textureId = floor(vTextureId + 0.5);\n\
\n\
vec4 color;\n\
%forloop%\n\
if (color.a < 0.01)\n\
{\n\
discard;\n\
}\n\
vec3 white = vec3(color.a, color.a, color.a);\n\
gl_FragColor = vec4(mix(color.rgb, white, vFade), color.a);\n\
}";
__extends(Shader, _super);
FLOAT_SIZE = 4;
function Shader(gl, maxTextures)
{
var _this = _super.call(this, gl, maxTextures, RECT_SHADER_VERTEX, PIXI.tilemap.shaderGenerator.generateFragmentSrc(maxTextures, RECT_SHADER_FRAGMENT)) || this;
_this.vertSize = 11;
_this.vertPerQuad = 4;
_this.stride = _this.vertSize * FLOAT_SIZE;
PIXI.tilemap.shaderGenerator.fillSamplers(_this, _this.maxTextures);
return _this;
}
Shader.prototype.createVao = function(renderer, vb)
{
var gl = renderer.gl;
this.uniforms.mode7ProjectionMatrix = $gameMap.ultraMode7ProjectionMatrix.data;
this.uniforms.mode7ModelviewMatrix = $gameMap.ultraMode7ModelviewMatrix.data;
return renderer.createVao()
.addIndex(this.indexBuffer)
.addAttribute(vb, this.attributes.aVertexPosition, gl.FLOAT, false, this.stride, 0)
.addAttribute(vb, this.attributes.aTextureCoord, gl.FLOAT, false, this.stride, 2 * FLOAT_SIZE)
.addAttribute(vb, this.attributes.aFrame, gl.FLOAT, false, this.stride, 4 * FLOAT_SIZE)
.addAttribute(vb, this.attributes.aAnim, gl.FLOAT, false, this.stride, 8 * FLOAT_SIZE)
.addAttribute(vb, this.attributes.aTextureId, gl.FLOAT, false, this.stride, 10 * FLOAT_SIZE)
};
return Shader;
}(PIXI.tilemap.TilemapShader));
//=============================================================================
// PIXI.tilemap.TileRenderer
//=============================================================================
if (UltraMode7.TILEMAP_PIXELATED)
{
PIXI.tilemap.TileRenderer.SCALE_MODE = PIXI.SCALE_MODES.NEAREST;
}
else
{
PIXI.tilemap.TileRenderer.SCALE_MODE = PIXI.SCALE_MODES.LINEAR;
}
var UltraMode7_PIXI_tilemap_TileRenderer_prototype_onContextChange = PIXI.tilemap.TileRenderer.prototype.onContextChange;
PIXI.tilemap.TileRenderer.prototype.onContextChange = function()
{
UltraMode7_PIXI_tilemap_TileRenderer_prototype_onContextChange.call(this);
this._ultraMode7Shader = new UltraMode7.Shader(this.renderer.gl, this.maxTextures);
this._ultraMode7Shader.indexBuffer = this.indexBuffer;
};
var UltraMode7_PIXI_tilemap_TileRenderer_prototype_destroy = PIXI.tilemap.TileRenderer.prototype.destroy;
PIXI.tilemap.TileRenderer.prototype.destroy = function()
{
UltraMode7_PIXI_tilemap_TileRenderer_prototype_destroy.call(this);
this._ultraMode7Shader.destroy();
this._ultraMode7Shader = null;
};
var UltraMode7_PIXI_tilemap_TileRenderer_prototype_getShader = PIXI.tilemap.TileRenderer.prototype.getShader;
PIXI.tilemap.TileRenderer.prototype.getShader = function (useSquare)
{
if (!$gameMap.useUltraMode7)
{
return UltraMode7_PIXI_tilemap_TileRenderer_prototype_getShader.call(this, useSquare);
}
return this._ultraMode7Shader;
};
//=============================================================================
// PIXI.tilemap.RectTileLayer
//=============================================================================
var UltraMode7_PIXI_tilemap_RectTileLayer_prototype_renderWebGL = PIXI.tilemap.RectTileLayer.prototype.renderWebGL;
PIXI.tilemap.RectTileLayer.prototype.renderWebGL = function(renderer, useSquare)
{
if (!$gameMap || !$gameMap.useUltraMode7)
{
UltraMode7_PIXI_tilemap_RectTileLayer_prototype_renderWebGL.call(this, renderer, useSquare);
return;
}
var points = this.pointsBuf;
if (points.length === 0)
{
return;
}
var tile = renderer.plugins.tilemap;
var shader = tile.getShader(useSquare);
var textures = this.textures;
if (textures.length === 0)
{
return;
}
var rectsCount = points.length / 9;
if (rectsCount === 0)
{
return;
}
var gl = renderer.gl;
var length = textures.length;
if (this._tempTexSize < shader.maxTextures)
{
this._tempTexSize = shader.maxTextures;
this._tempSize = new Float32Array(2 * shader.maxTextures);
}
var i = 0;
for (i = 0; i < length; ++i)
{
if (!textures || !textures.valid)
{
return;
}
var texture = textures.baseTexture;
}
if (!this.vbIds)
{
this.vbIds = [];
this.vbBuffers = [];
this.modificationMarkers = [];
this.vbArrays = [];
}
tile.checkIndexBuffer(rectsCount);
tile.bindTextures(renderer, shader, textures);
shader.uniforms.mode7ProjectionMatrix = $gameMap.ultraMode7ProjectionMatrix.data;
shader.uniforms.mode7ModelviewMatrix = $gameMap.ultraMode7ModelviewMatrix.data;
var maxRects = UltraMode7.WEBGL_MAX_VERTICES / shader.vertPerQuad;
var maxLoops = Math.floor((rectsCount + maxRects - 1) / maxRects);
for (var j = 0; j < maxLoops; ++j)
{
if (!this.vbIds[j])
{
this.vbIds[j] = 0;
this.vbBuffers[j] = null;
this.modificationMarkers[j] = 0;
this.vbArrays[j] = null;
}
var currentRectsCount = Math.min(maxRects, rectsCount - j * maxRects);
var vb = tile.getVb(this.vbIds[j]);
if (!vb)
{
vb = tile.createVb(useSquare);
this.vbIds[j] = vb.id;
this.vbBuffers[j] = null;
this.modificationMarkers[j] = 0;
this.vbArrays[j] = null;
}
var vao = vb.vao;
renderer.bindVao(vao);
var vertexBuf = vb.vb;
vertexBuf.bind();
var currentVertices = currentRectsCount * shader.vertPerQuad;
if (this.modificationMarkers[j] !== currentVertices)
{
this.modificationMarkers[j] = currentVertices;
var vs = shader.stride * currentVertices;
if (!this.vbBuffers[j] || this.vbBuffers[j].byteLength < vs)
{
var bk = shader.stride;
while (bk < vs)
{
bk *= 2;
}
this.vbBuffers[j] = new ArrayBuffer(bk);
this.vbArrays[j] = new Float32Array(this.vbBuffers[j]);
vertexBuf.upload(this.vbBuffers[j], 0, true);
}
var arr = this.vbArrays[j];
var sz = 0;
var eps = 0.5;
for (i = j * maxRects * 9; i < points.length && i < (j + 1) * maxRects * 9; i += 9)
{
var x = points[i + 2];
var y = points[i + 3];
var w = points[i + 4];
var h = points[i + 5];
var u = points + 1024 * (points[i + 8] & 1);
var v = points[i + 1] + 1024 * ((points[i + 8] >> 1) & 1);
var animX = points[i + 6];
var animY = points[i + 7];
var textureId = (points[i + 8] >> 2);
arr[sz++] = x;
arr[sz++] = y;
arr[sz++] = u;
arr[sz++] = v;
arr[sz++] = u + eps;
arr[sz++] = v + eps;
arr[sz++] = u + w - eps;
arr[sz++] = v + h - eps;
arr[sz++] = animX;
arr[sz++] = animY;
arr[sz++] = textureId;
arr[sz++] = x + w;
arr[sz++] = y;
arr[sz++] = u + w;
arr[sz++] = v;
arr[sz++] = u + eps;
arr[sz++] = v + eps;
arr[sz++] = u + w - eps;
arr[sz++] = v + h - eps;
arr[sz++] = animX;
arr[sz++] = animY;
arr[sz++] = textureId;
arr[sz++] = x + w;
arr[sz++] = y + h;
arr[sz++] = u + w;
arr[sz++] = v + h;
arr[sz++] = u + eps;
arr[sz++] = v + eps;
arr[sz++] = u + w - eps;
arr[sz++] = v + h - eps;
arr[sz++] = animX;
arr[sz++] = animY;
arr[sz++] = textureId;
arr[sz++] = x;
arr[sz++] = y + h;
arr[sz++] = u;
arr[sz++] = v + h;
arr[sz++] = u + eps;
arr[sz++] = v + eps;
arr[sz++] = u + w - eps;
arr[sz++] = v + h - eps;
arr[sz++] = animX;
arr[sz++] = animY;
arr[sz++] = textureId;
}
vertexBuf.upload(arr, 0, true);
}
gl.drawElements(gl.TRIANGLES, currentRectsCount * 6, gl.UNSIGNED_SHORT, 0);
}
};
//=============================================================================
// Tilemap
//=============================================================================
var UltraMode7_Tilemap_prototype_initialize = Tilemap.prototype.initialize;
Tilemap.prototype.initialize = function()
{
if (!$gameMap.useUltraMode7)
{
UltraMode7_Tilemap_prototype_initialize.call(this);
return;
}
PIXI.Container.call(this);
this._margin = 0;
this._width = $gameMap.width() * $gameMap.tileWidth();
this._height = $gameMap.height() * $gameMap.tileHeight();
this._tileWidth = 48;
this._tileHeight = 48;
this._mapWidth = 0;
this._mapHeight = 0;
this._mapData = null;
this._layerWidth = 0;
this._layerHeight = 0;
this._lastTiles = [];
this.bitmaps = [];
this.origin = new Point();
this.flags = [];
this.animationCount = 0;
this.horizontalWrap = false;
this.verticalWrap = false;
this._createLayers();
this.refresh();
};
//=============================================================================
// ShaderTilemap
//=============================================================================
var UltraMode7_ShaderTilemap_prototype__createLayers = ShaderTilemap.prototype._createLayers;
ShaderTilemap.prototype._createLayers = function()
{
if (!$gameMap.useUltraMode7)
{
UltraMode7_ShaderTilemap_prototype__createLayers.call(this);
return;
}
// width/height forcing is needed, because some scripts manipulate the width and height values of the tilemap
this._width = $gameMap.width() * $gameMap.tileWidth();
this._height = $gameMap.height() * $gameMap.tileHeight();
var width = this._width;
var height = this._height;
var margin = this._margin;
var tileCols = Math.ceil(width / this._tileWidth) + 1;
var tileRows = Math.ceil(height / this._tileHeight) + 1;
var layerWidth = this._layerWidth = tileCols * this._tileWidth;
var layerHeight = this._layerHeight = tileRows * this._tileHeight;
this._needsRepaint = true;
if (!this.lowerZLayer)
{
this.lowerZLayer = new PIXI.tilemap.ZLayer(this, 0);
this.upperZLayer = new PIXI.tilemap.ZLayer(this, 0);
this.addChild(this.lowerZLayer);
this.addChild(this.upperZLayer);
var parameters = PluginManager.parameters('ShaderTilemap');
var useSquareShader = Number(parameters.hasOwnProperty('squareShader') ? parameters['squareShader'] : 0);
this.lowerLayer = new PIXI.tilemap.CompositeRectTileLayer(0, [], useSquareShader);
this.lowerLayer.shadowColor = new Float32Array([0.0, 0.0, 0.0, 0.5]);
this.lowerZLayer.addChild(this.lowerLayer);
this.upperLayer = new PIXI.tilemap.CompositeRectTileLayer(0, [], useSquareShader);
this.upperZLayer.addChild(this.upperLayer);
}
};
var UltraMode7_ShaderTilemap_prototype__updateLayerPositions = ShaderTilemap.prototype._updateLayerPositions;
ShaderTilemap.prototype._updateLayerPositions = function(startX, startY)
{
if (!$gameMap.useUltraMode7)
{
UltraMode7_ShaderTilemap_prototype__updateLayerPositions.call(this, startX, startY);
}
};
var UltraMode7_ShaderTilemap_prototype__paintAllTiles = ShaderTilemap.prototype._paintAllTiles;
ShaderTilemap.prototype._paintAllTiles = function(startX, startY)
{
if (!$gameMap.useUltraMode7)
{
UltraMode7_ShaderTilemap_prototype__paintAllTiles.call(this, startX, startY);
return;
}
this.lowerZLayer.clear();
this.upperZLayer.clear();
var tileCols = Math.ceil(this._width / this._tileWidth) + 1;
var tileRows = Math.ceil(this._height / this._tileHeight) + 1;
for (var y = 0; y < tileRows; ++y)
{
for (var x = 0; x < tileCols; ++x)
{
this._paintTiles(0, 0, x, y);
}
}
};
//=============================================================================
// Game_CharacterBase
//=============================================================================
var UltraMode7_Game_CharacterBase_prototype_screenX = Game_CharacterBase.prototype.screenX;
Game_CharacterBase.prototype.screenX = function()
{
var x = UltraMode7_Game_CharacterBase_prototype_screenX.call(this);
if (!$gameMap.useUltraMode7)
{
return x;
}
var y = UltraMode7_Game_CharacterBase_prototype_screenY.call(this);
var ultraMode7Position = UltraMode7.mapToScreen(x, y);
return (this.isUltraMode7Visible(ultraMode7Position.z) ? ultraMode7Position.x : -10000);
};
var UltraMode7_Game_CharacterBase_prototype_screenY = Game_CharacterBase.prototype.screenY;
Game_CharacterBase.prototype.screenY = function()
{
var y = UltraMode7_Game_CharacterBase_prototype_screenY.call(this);
if (!$gameMap.useUltraMode7)
{
return y;
}
var x = UltraMode7_Game_CharacterBase_prototype_screenX.call(this);
var ultraMode7Position = UltraMode7.mapToScreen(x, y);
return (this.isUltraMode7Visible(ultraMode7Position.z) ? ultraMode7Position.y : -10000);
};
Game_CharacterBase.prototype.screenScale = function()
{
if (!$gameMap.useUltraMode7)
{
return 1.0;
}
var x = UltraMode7_Game_CharacterBase_prototype_screenX.call(this);
var y = UltraMode7_Game_CharacterBase_prototype_screenY.call(this);
return UltraMode7.mapToScreenScale(x, y);
};
Game_CharacterBase.prototype.isUltraMode7Visible = function(z)
{
if (!$gameMap.useUltraMode7)
{
return true;
}
return (z > UltraMode7.NEAR_CLIP_Z && z < UltraMode7.FAR_CLIP_Z);
};
//=============================================================================
// Game_Map
//=============================================================================
Object.defineProperties(Game_Map.prototype,
{
useUltraMode7: { get: function() { return this._useUltraMode7; }, configurable: true },
ultraMode7Fov: { get: function() { return this._ultraMode7Fov; }, configurable: true },
ultraMode7Pitch: { get: function() { return this._ultraMode7Pitch; }, configurable: true },
ultraMode7Yaw: { get: function() { return this._ultraMode7Yaw; }, configurable: true },
ultraMode7CameraDistance: { get: function() { return this._ultraMode7CameraDistance; }, configurable: true },
ultraMode7ProjectionMatrix: { get: function() { return this._ultraMode7ProjectionMatrix; }, configurable: true },
ultraMode7ModelviewMatrix: { get: function() { return this._ultraMode7ModelviewMatrix; }, configurable: true }
});
var UltraMode7_Game_Map_prototype_initialize = Game_Map.prototype.initialize;
Game_Map.prototype.initialize = function()
{
UltraMode7_Game_Map_prototype_initialize.call(this);
this.initUltraMode7();
};
var UltraMode7_Game_Map_prototype_setup = Game_Map.prototype.setup;
Game_Map.prototype.setup = function(mapId)
{
UltraMode7_Game_Map_prototype_setup.call(this, mapId);
this.setupUltraMode7();
};
Game_Map.prototype.initUltraMode7 = function()
{
this._useUltraMode7 = false;
this._ultraMode7Pitch = 0;
this._ultraMode7Yaw = 0;
this._ultraMode7CameraDistance = Graphics.boxWidth / 2;
this._ultraMode7ProjectionMatrix = new UltraMode7.Matrix4();
this._ultraMode7ModelviewMatrix = new UltraMode7.Matrix4();
var eye = new UltraMode7.Vector3(0, 0, this._ultraMode7CameraDistance);
var target = new UltraMode7.Vector3(0, 0, 0);
var up = new UltraMode7.Vector3(0, 1, 0);
this._ultraMode7ModelviewMatrix.lookAt(eye, target, up);
};
Game_Map.prototype.setupUltraMode7 = function()
{
this.initUltraMode7();
if (!$dataMap)
{
throw new Error("The map data is not available");
}
if ($dataMap.meta.UltraMode7 || $dataMap.meta.UltraMode7_FOV || $dataMap.meta.UltraMode7_Pitch ||
$dataMap.meta.UltraMode7_Yaw || $dataMap.meta.UltraMode7_CameraDistance)
{
this._useUltraMode7 = true;
this._ultraMode7Fov = Math.max(BlizzardUtility.Numeric($dataMap.meta.UltraMode7_FOV, UltraMode7.DEFAULT_FOV), UltraMode7.MIN_FOV);
this._ultraMode7Pitch = BlizzardUtility.Numeric($dataMap.meta.UltraMode7_Pitch, UltraMode7.DEFAULT_PITCH).clamp(UltraMode7.MIN_PITCH, UltraMode7.MAX_PITCH);
this._ultraMode7Yaw = BlizzardUtility.Numeric($dataMap.meta.UltraMode7_Yaw, UltraMode7.DEFAULT_YAW);
this._ultraMode7CameraDistance = Math.max(BlizzardUtility.Numeric($dataMap.meta.UltraMode7_CameraDistance, UltraMode7.DEFAULT_CAMERA_DISTANCE), 0);
this.refreshUltraMode7View();
}
};
Game_Map.prototype.setUltraMode7Fov = function(value)
{
if (!this._useUltraMode7)
{
return;
}
this._ultraMode7Fov = Math.max(value, UltraMode7.MIN_FOV); // more or less arbitrary limit, but there are huge issues with smaller values
this.refreshUltraMode7View();
};
Game_Map.prototype.setUltraMode7Pitch = function(value)
{
if (!this._useUltraMode7)
{
return;
}
this._ultraMode7Pitch = value.clamp(UltraMode7.MIN_PITCH, UltraMode7.MAX_PITCH);
this.refreshUltraMode7View();
};
Game_Map.prototype.setUltraMode7Yaw = function(value)
{
if (!this._useUltraMode7)
{
return;
}
this._ultraMode7Yaw = value;
this.refreshUltraMode7View();
};
Game_Map.prototype.setUltraMode7CameraDistance = function(value)
{
if (!this._useUltraMode7)
{
return;
}
this._ultraMode7CameraDistance = Math.max(value, 0);
this.refreshUltraMode7View();
};
Game_Map.prototype.refreshUltraMode7View = function()
{
if (!this._useUltraMode7)
{
return;
}
this._ultraMode7ProjectionMatrix.setPerspective(this._ultraMode7Fov, Graphics.boxWidth, Graphics.boxHeight, UltraMode7.NEAR_CLIP_Z, UltraMode7.FAR_CLIP_Z);
var eye = new UltraMode7.Vector3(0, 0, this._ultraMode7CameraDistance);
var target = new UltraMode7.Vector3(0, 0, 0);
var up = new UltraMode7.Vector3(0, 1, 0);
this._ultraMode7ModelviewMatrix.lookAt(eye, target, up);
this._ultraMode7ModelviewMatrix.rotateX($gameMap.ultraMode7Pitch);
this._ultraMode7ModelviewMatrix.rotateZ($gameMap.ultraMode7Yaw);
this._ultraMode7ModelviewMatrix.translate(-Graphics.boxWidth / 2 - $gameMap.displayX() * $gameMap.tileWidth(), -Graphics.boxHeight / 2 - $gameMap.displayY() * $gameMap.tileHeight(), 0);
};
var UltraMode7_Game_Map_prototype_parallaxOx = Game_Map.prototype.parallaxOy;
Game_Map.prototype.parallaxOx = function()
{
if (!this._useUltraMode7)
{
return UltraMode7_Game_Map_prototype_parallaxOx.call(this);
}
if (this._parallaxZero)
{
return (this._parallaxX * UltraMode7.PARALLAX_SCROLL_X_MULTIPLIER * this.tileWidth());
}
if (this._parallaxLoopX)
{
return (this._parallaxX * UltraMode7.PARALLAX_SCROLL_X_MULTIPLIER * this.tileWidth() / 2);
}
return 0;
};
var UltraMode7_Game_Map_prototype_parallaxOy = Game_Map.prototype.parallaxOy;
Game_Map.prototype.parallaxOy = function()
{
if (!this._useUltraMode7)
{
return UltraMode7_Game_Map_prototype_parallaxOy.call(this);
}
if (this._parallaxZero)
{
return (this._parallaxY * UltraMode7.PARALLAX_SCROLL_Y_MULTIPLIER * this.tileHeight());
}
if (this._parallaxLoopY)
{
return (this._parallaxY * UltraMode7.PARALLAX_SCROLL_Y_MULTIPLIER * this.tileHeight() / 2);
}
return 0;
};
var UltraMode7_Game_Map_prototype_setDisplayPos = Game_Map.prototype.setDisplayPos;
Game_Map.prototype.setDisplayPos = function(x, y)
{
if (!this._useUltraMode7)
{
UltraMode7_Game_Map_prototype_setDisplayPos.call(this, x, y);
return;
}
if (this.isLoopHorizontal())
{
this._displayX = x.mod(this.width());
this._parallaxX = x;
}
else
{
var screenTileX = this.screenTileX();
var endX = this.width() - screenTileX;
this._displayX = x;
this._parallaxX = this._displayX;
}
if (this.isLoopVertical())
{
this._displayY = y.mod(this.height());
this._parallaxY = y;
}
else
{
var endY = this.height() - this.screenTileY();
this._displayY = y;
this._parallaxY = this._displayY;
}
this.refreshUltraMode7View();
};
var UltraMode7_Game_Map_prototype_scrollDown = Game_Map.prototype.scrollDown;
Game_Map.prototype.scrollDown = function(distance)
{
if (!this._useUltraMode7)
{
UltraMode7_Game_Map_prototype_scrollDown.call(this, distance);
return;
}
this._displayY += distance;
if (this.isLoopVertical())
{
this._displayY %= $dataMap.height;
if (this._parallaxLoopY)
{
this._parallaxY += distance;
}
}
else
{
this._parallaxY += distance;
}
this.refreshUltraMode7View();
};
var UltraMode7_Game_Map_prototype_scrollLeft = Game_Map.prototype.scrollLeft;
Game_Map.prototype.scrollLeft = function(distance)
{
if (!this._useUltraMode7)
{
UltraMode7_Game_Map_prototype_scrollLeft.call(this, distance);
return;
}
if (this.isLoopHorizontal())
{
this._displayX += $dataMap.width - distance;
this._displayX %= $dataMap.width;
if (this._parallaxLoopX)
{
this._parallaxX -= distance;
}
}
else
{
this._displayX -= distance;
this._parallaxX -= distance;
}
this.refreshUltraMode7View();
};
var UltraMode7_Game_Map_prototype_scrollRight = Game_Map.prototype.scrollRight;
Game_Map.prototype.scrollRight = function(distance)
{
if (!this._useUltraMode7)
{
UltraMode7_Game_Map_prototype_scrollRight.call(this, distance);
return;
}
this._displayX += distance;
if (this.isLoopHorizontal())
{
this._displayX %= $dataMap.width;
if (this._parallaxLoopX)
{
this._parallaxX += distance;
}
}
else
{
this._parallaxX += distance;
}
this.refreshUltraMode7View();
};
var UltraMode7_Game_Map_prototype_scrollUp = Game_Map.prototype.scrollUp;
Game_Map.prototype.scrollUp = function(distance)
{
if (!this._useUltraMode7)
{
UltraMode7_Game_Map_prototype_scrollUp.call(this, distance);
return;
}
if (this.isLoopVertical())
{
this._displayY += $dataMap.height - distance;
this._displayY %= $dataMap.height;
if (this._parallaxLoopY)
{
this._parallaxY -= distance;
}
}
else
{
this._displayY -= distance;
this._parallaxY -= distance;
}
this.refreshUltraMode7View();
};
var UltraMode7_Game_Map_prototype_update = Game_Map.prototype.update;
Game_Map.prototype.update = function(sceneActive)
{
UltraMode7_Game_Map_prototype_update.call(this, sceneActive);
if (this._useUltraMode7)
{
this.updateUltraMode7();
}
};
Game_Map.prototype.updateUltraMode7 = function()
{
var needRefresh = false;
if (this._ultraMode7FovDuration > 0)
{
var duration = this._ultraMode7FovDuration;
this._ultraMode7Fov = Math.max((this._ultraMode7Fov * (duration - 1) + this._ultraMode7FovTarget) / duration, UltraMode7.MIN_FOV);
--this._ultraMode7FovDuration;
needRefresh = true;
}
if (this._ultraMode7PitchDuration > 0)
{
var duration = this._ultraMode7PitchDuration;
this._ultraMode7Pitch = ((this._ultraMode7Pitch * (duration - 1) + this._ultraMode7PitchTarget) / duration).clamp(UltraMode7.MIN_PITCH, UltraMode7.MAX_PITCH);
--this._ultraMode7PitchDuration;
needRefresh = true;
}
if (this._ultraMode7YawDuration > 0)
{
var duration = this._ultraMode7YawDuration;
this._ultraMode7Yaw = (this._ultraMode7Yaw * (duration - 1) + this._ultraMode7YawTarget) / duration;
--this._ultraMode7YawDuration;
needRefresh = true;
}
if (this._ultraMode7CameraDistanceDuration > 0)
{
var duration = this._ultraMode7CameraDistanceDuration;
this._ultraMode7CameraDistance = Math.max((this._ultraMode7CameraDistance * (duration - 1) + this._ultraMode7CameraDistanceTarget) / duration, 0);
--this._ultraMode7CameraDistanceDuration;
needRefresh = true;
}
if (needRefresh)
{
this.refreshUltraMode7View();
}
};
Game_Map.prototype.animateUltraMode7Fov = function(target, frameDuration)
{
this._ultraMode7FovTarget = target;
this._ultraMode7FovDuration = frameDuration;
};
Game_Map.prototype.animateUltraMode7Pitch = function(target, frameDuration)
{
this._ultraMode7PitchTarget = target;
this._ultraMode7PitchDuration = frameDuration;
};
Game_Map.prototype.animateUltraMode7Yaw = function(target, frameDuration)
{
this._ultraMode7YawTarget = target;
this._ultraMode7YawDuration = frameDuration;
};
Game_Map.prototype.animateUltraMode7CameraDistance = function(target, frameDuration)
{
this._ultraMode7CameraDistanceTarget = target;
this._ultraMode7CameraDistanceDuration = frameDuration;
};
//=============================================================================
// Sprite_Character
//=============================================================================
var UltraMode7_Sprite_Character_prototype_updateBitmap = Sprite_Character.prototype.updateBitmap;
Sprite_Character.prototype.updateBitmap = function()
{
var imageChanged = this.isImageChanged();
UltraMode7_Sprite_Character_prototype_updateBitmap.call(this);
if ($gameMap.useUltraMode7 && imageChanged && this.bitmap)
{
this.bitmap.smooth = !UltraMode7.CHARACTERS_PIXELATED;
}
};
var UltraMode7_Sprite_Character_prototype_characterPatternY = Sprite_Character.prototype.characterPatternY;
Sprite_Character.prototype.characterPatternY = function()
{
if (!$gameMap.useUltraMode7)
{
return UltraMode7_Sprite_Character_prototype_characterPatternY.call(this);
}
var direction = this._character.direction();
var angle = $gameMap.ultraMode7Yaw;
if (angle >= 45 && angle <= 135)
{
switch (direction)
{
case 2: direction = 4; break;
case 4: direction = 8; break;
case 6: direction = 2; break;
case 8: direction = 6; break;
default: break;
}
}
else if (angle > 135 && angle < 225)
{
direction = 10 - direction;
}
else if (angle >= 225 && angle <= 315)
{
switch (direction)
{
case 2: direction = 6; break;
case 4: direction = 2; break;
case 6: direction = 8; break;
case 8: direction = 4; break;
default: break;
}
}
return (direction - 2) / 2;
};
var UltraMode7_Sprite_Character_prototype_updatePosition = Sprite_Character.prototype.updatePosition;
Sprite_Character.prototype.updatePosition = function()
{
UltraMode7_Sprite_Character_prototype_updatePosition.call(this);
if (!$gameMap.useUltraMode7)
{
return;
}
var scale = this._character.screenScale();
this.scale.x = scale;
this.scale.y = scale;
};
//=============================================================================
// Sprite_Destination
//=============================================================================
var UltraMode7_Sprite_Destination_prototype_updatePosition = Sprite_Destination.prototype.updatePosition;
Sprite_Destination.prototype.updatePosition = function()
{
UltraMode7_Sprite_Destination_prototype_updatePosition.call(this);
if (!$gameMap.useUltraMode7)
{
return;
}
var position = UltraMode7.mapToScreen(this.x, this.y);
this.x = position.x;
this.y = position.y;
};
//=============================================================================
// Scene_Map
//=============================================================================
var UltraMode7_Scene_Map_prototype_processMapTouch = Scene_Map.prototype.processMapTouch;
Scene_Map.prototype.processMapTouch = function()
{
if (!$gameMap.useUltraMode7)
{
UltraMode7_Scene_Map_prototype_processMapTouch.call(this);
return;
}
if (TouchInput.isTriggered() || this._touchCount > 0)
{
if (TouchInput.isPressed())
{
if (this._touchCount === 0 || this._touchCount >= 15)
{
var position = UltraMode7.screenToMap(TouchInput.x, TouchInput.y);
$gameTemp.setDestination(Math.floor(position.x / $gameMap.tileWidth()), Math.floor(position.y / $gameMap.tileHeight()));
}
this._touchCount++;
}
else
{
this._touchCount = 0;
}
}
};
//=============================================================================
})();
[/pre]
範本下載
https://downloads.chaos-project.com/scripts/UltraMode7.zip
百度1k上傳中
链接：https://pan.baidu.com/s/1o3Hjdv33sebMRdDLcDQtHA 密码：nuq0 |
|
写轮眼
发表于 2018-4-26 10:37:53
提升卡
沉默号角
喧嚣号角
变色卡
升龙剑
